NEMA 6-20P to C13 Y Splitter Cables
AC Power Cords, NEMA 6-20P to C13 Y Splitter Cords, 15A, 125V, 14/3 SJT Jacket
.png)
Specifications:
| Plug Type | NEMA 6-20P |
| Connector Type | IEC C13 x2 |
| Length | 4 Feet (2 ft lead + 2 ft legs) |
| Amperage | 15 Amps |
| Voltage | 250V |
| Number of Conductors | 3 |
| Wire Gauge | 14 AWG |
| Jacket Type | SJT |
| Temperature Rating |
105º C |
| Color | Black |
| Testing | Tested for Voltage Hi-Potential, Continuity, and Polarity |
| Certifications | UL Listed |
Applications: Plug two devices with a C14 male plug on the power supply into a single 6-20R outlet
AKA: C13 6-20P Splitter Cords, NEMA 6-20P to C13 Splitter Cord, 2 Way Splitter Cable
Part Number: IBX-2740-04 (04 = Length)
