L14-30P to 6-20R Plug Adapter Power Cord

L14-30P to 6-20R Plug Adapter Power Cord

$61.86

NEMA L14-30P to 6-20R Power Adapter Cables

SKU: IBX-1462

NEMA L14-30P to 6-20R Power Cord Plug Adapter, 1 Foot, 20A, 250V

14 30p to 6 20r



Specifications:

Plug Type                        L14-30P
Connector Type 6-20R
Length 1 Foot (Custom Lengths Available)
Amperage 20 Amps
Voltage                               250V
Number of Conductors 3
Wire Gauge 12 AWG
Jacket Type SJT
Temperature Rating
 105º C
Color Black
Testing Tested for Voltage Hi-Potential, Continuity, and Polarity

Technical Notes:  Make sure your device doesn’t need more amps than the outlet allows

 Applications: Convert a NEMA straight blade 6-20P plug to fit into a NEMA L14-30R locking receptacle

   Part Number: IBX-1462
